StackMatch, 3000W, 2 antennas, wide band
SKU:
SM3kW2-WB-N
Availability: By Order
- Overview
SM3kW series of Stacking Switches
Wide band Stacking switch SM3kW2-WB
Multiplexer technology ready ©
Non used ports loaded to 50 ohms resistors.
Can be used in building high power matrix multiplexer distribution systems.
Band: 7-30 Mhz (any other freq.range on request)
≤ 0,05 db at 30MHz
00W at 1,5 : 1 SWR
Any combination of antennas:
Default position is both antennas ON
To switch Amtenna #1 - 12Vdc (24Vdc on request) Pin#1
To switch Amtenna #2 - 12Vdc (24Vdc on request) Pin#2
Control voltage: 12Vdc
