QuadPlexer «Perfo Box-500», 500W ICAS, 7-10-14-18 MHz
SKU:
PB-QP50040302018
Availability: In Stock
- Overview
- Additional Information
Download:
Detailed data sheet of QuadPlexer «Perfo Box-500»
Typical specifications:
| Impedance: | 50 Ohm |
| Maximum ICAS power per band port: | 500 W |
| Maximum ICAS power at antenna port: | 1500 W |
| VSWR: | typical ≤1: 1,2 |
| Cooling fans: | 12VDC, 2200RPM, 29.9CFM |
| Size: | 360x240x110 mm / 14”х10”х4” |
| Net weight: | ≤3,2 kg / 7,5 lbs |
| Band, MHz: | 7 - 10 - 14 - 18 |
| Power, Watts, ICAS: | 500 |
