Di-, Tri-, Quad-, PentaPlexers 1.5kW

QuadPlexer «Perfo Box-1500», 1500W ICAS, 7-14-21-28 MHz

SKU: PB-QP1500

Availability: In Stock

Overview
Additional Information

Download:

Detailed data sheet of QuadPlexer «Perfo Box-1500»

Application Note AN_MP-01 “Using High Performance Multiplexers to improve your HF station Capability”

Typical specifications:

Impedance:	50 Ohm
Maximum ICAS power per band port:	1500 W
Maximum ICAS power at antenna port:	3000 W
VSWR:	typical ≤1: 1,2
Cooling fans:	12VDC, 2200RPM, 29.9CFM
Size:	360x240x110 mm / 14”х10”х4”
Net weight:	≤3,2 kg / 7,5 lbs

Band, MHz:	7 - 14 - 21 - 28
Power, Watts, ICAS:	1500
