TriPlexer «Perfo Box-1500», 1500W ICAS, 10-18-24 MHz

SKU: PB-TP1500301812
Availability: By Order
350 Eur
add to compare Compare
  • Overview
  • Additional Information

Download:



Detailed data sheet of TriPlexer «Perfo Box-1500»



Application Note AN_MP-01  “Using High Performance Multiplexers to improve your HF station Capability”

Typical specifications:

Impedance:        50 Ohm
Maximum ICAS power per band port: 1500 W
Maximum ICAS power at antenna port: 3000 W
VSWR:    typical ≤1: 1,25
Cooling fans:  12VDC, 2200RPM, 29.9CFM
Size:  275x240x105 mm / 11”х10”х4”
Net weight:  ≤2,0 kg / 4,5 lbs





Band, MHz: 10 - 18 - 24
Power, Watts, ICAS: 1500
