Transmit Stack Matches

StackMatch, 3000W, 4 antennas, 28Mhz

SKU: SM3kW4-10-N

Availability: By Order

Overview

SM4-3kW series of Stacking Switces

Mono band Stacking switch SM4-3kW-28Mhz

Multiplexer technology ready ©

Unselected antenna ports are terminated 50 Ohm, 8W.

Can be used with high power multiplexer distribution systems.

Three optimized matching networks for 2, 3 or 4 antenna stacking.

Control options: any single antemma or one of 14 (yes, fourteen) combination of antennas!

LEDs helping to visualize antennas selected.

5 silver plated quality UHF (SO-239) connectors.

Control: 12Vdc, MOV protected for all seven control lines.

Band: 28 Mhz

VSWR: ≤ 1:1,05 28Mhz

Losses: ≤ 0,1 db at 28MHz

Power, Watts, ICAS - 3000W at 1,5 : 1 SWR
