Receive Antenna Switch "RS8BCD", 50 ohm, UHF connectors

Availability: By Order
120 Eur
add to compare Compare
  • Overview

Remote antenna switch specifically designed for low band receive antenna systems


  • Specifications:

    • 50 OHM impedance coaxial cable one of eight switch
    • Remotely Switch One of eight receiving Antennas
    • DC inject to selected inputs, protected by polyfuse to save power source
    • Remote operation can be switched by activating +13.8 VDC
    • Provides a 1 Watt 75 ohm termination for non-switched inputs
    • Greater than 60 dB of on to off isolation from 50 KHz to 10 MHz
    • Greater than 60 dB of isolation from 50 KHz to 10 MHz to unused ports
    • SWR contribution less than 1.15: 1 from 50 KHz to 10 MHz
    • Quality F connectors
    • Perfect for Beverage antennas needing non-selected antennas terminated
    • High Quality, specaly dsigned telecome relays for a good low current tarnsfer and a long life
    • Perfect for switching with CAT5 or CAT6 computer cable
    • Available in a version with Preamplifiers
    • Compatable with LowBandSystems LBC8ARD control console as well as with DXEngineering CC-8A Deluxe Control Consoles
