High Power 4 direction Transmit system. PCB only, assembled, tested.

High Power, 4 direction Transmit system, 4 only vertical elements, 7kW CW ICAS.

LowBandSytem`s 4SQUARE/TX Switch Relay Units use classic monoband Hybrid design.

Power, Watts, ICAS: 7000W at 1,5 : 1 SWR, ICAS

Robust, Inert gas filled high current relays from Soviet Army (REN-33, 27VDC coils) and К15У-1capasitors.

SO-239 input and output connector with PTFE Dielectric and Silver Plating.

N connectors on demand.

DIN 7/16 input connector on demand.

RF volatge detector to control DUMPED power on a system`s load resistor.

3 wires control line.

Phoenix plugable connector.

Switch relay units are made to any band of your choise, 160-10 meters.

80 meters system requiers also CW stub remote relay switches at the base of each vertical.

These switch relay unit requires:

One of the LowBandSytems 4 SQUARE ARRAY controllers:

4 SQUARE ARRAY, 4 DIRECTION CONTROLLER LBC4

Universal Control Console "UCC-8"

4 SQUARE ARRAY, 4 DIRECTION CONTROLLER SMART-4

PCB size: 210 x 150 x 70 mm / 8,3``x 5,9``x 2,8``

PCB net weight: 1,4 kg / 3,1 lbs
